Have you ever experienced an API receive far more calls than expected?

Sometimes a system sends requests too quickly, a script keeps retrying, or traffic suddenly spikes. When that happens, the API can get overloaded. Response times slow down, CPU usage increases, and in some cases the server may stop responding entirely.

Even a small mistake or bug can push an API beyond its limits if there is no control over how many requests are allowed in a given time. This is where rate limiting becomes essential for keeping the system healthy and stable.

This blog focuses on the Fixed Window Rate Limiter, which is one of the simplest and most reliable way to manage traffic in ASP.NET Core.

Rate Limiting: What Is It?

Rate limiting controls how often users or systems can call an API.

It helps the system stay secure and stable when:

• Traffic suddenly increases

• Scripts or scheduled jobs repeatedly make calls

• Brute-force attacks or accidental request floods occur

With rate limiting in place, the API stays fair and consistent for all clients.

For a general introduction to ASP.NET Core rate limiting, refer to the first blog in this series:

"Introduction: Rate Limiting Middleware in ASP.NET Core"

What Is a Fixed Window Rate Limiter?

The Fixed Window limiter divides time into fixed windows. Each window has a set number of requests allowed. After the limit is reached, any extra requests in that same time window are rejected. When the next window begins, the counter resets and new requests are allowed again.

Simple explanation

• Time is divided into fixed windows (e.g., every 10 minutes)

• Only a certain number of requests are allowed in each window (e.g., 5 requests)

• Once the limit is crossed, all extra calls are blocked until the next window starts

This method works well for predictable traffic and internal systems where usage patterns don’t vary much.

Example Scenario

Imagine an API that generates an Inventory Report.

The report is heavy and takes time to process.

Typically, it receives 2–5 calls every 10 minutes. But because of a scheduling issue, the API suddenly received 40+ requests in the same 10-minute window. This overloaded the database and affected the entire system.

What Happened Without a Rate Limiter

• CPU usage went higher than usual

• Report processing time increased

• Other APIs slowed down

• System stability dropped

What Happened After Adding a Fixed Window Limiter

• Only 5 requests were allowed every 10 minutes

• Extra calls were immediately blocked

• CPU usage dropped

• Report generation became faster

• The system remained stable and responsive

This shows how even a simple rate limiter can protect a system from unplanned load.

Below is a sample implementation of a Fixed Window limiter:

var builder = WebApplication.CreateBuilder(args);

builder.Services.AddControllers();
builder.Services.AddEndpointsApiExplorer();

builder.Services.AddRateLimiter(options =>
{
    options.AddFixedWindowLimiter("InventoryReportLimit", limiterOptions =>
    {
        limiterOptions.PermitLimit = 5;                   // allow 5 API calls
        limiterOptions.Window = TimeSpan.FromMinutes(10); // per 10 minutes
        limiterOptions.QueueLimit = 0;
    });

    options.OnRejected = async (context, cancellationToken) =>
    {
        context.HttpContext.Response.StatusCode = StatusCodes.Status429TooManyRequests;
        await context.HttpContext.Response
                     .WriteAsync("Too many report requests. Try again later.");
    };
});

var app = builder.Build();
app.UseRouting();
app.UseRateLimiter();
app.MapControllers();

app.Run();

This configuration allows only five requests every ten minutes. Any additional requests during that window are rejected.

Advantages of Fixed Window Rate Limiter

• Prevents sudden traffic spikes from overloading the API

• Keeps the system stable by controlling how many requests enter

• Simple to understand and configure

When to Use the Fixed Window Limiter

Use this limiter when:

• Traffic is consistent and predictable

• Simple rate-limit rules are enough

• Internal or partner systems call the API

• A fixed number of requests per time window is acceptable

When Not to Use the Fixed Window Limiter

Avoid this limiter when:

• Traffic fluctuates heavily

• Smoother request distribution is needed (Sliding Window is a better option)

• Short-term bursts need to be allowed (Token Bucket is a better option)

• The goal is to limit concurrent execution rather than request count (Concurrency Limiter is a better option)

Summary

The Fixed Window Rate Limiter is an easy and effective way to protect APIs from heavy or unexpected traffic. It divides time into fixed intervals and allows only a certain number of requests within each interval. When applied correctly, it keeps the API fast, stable, and fair for all clients.

If you want to explore more rate limiting techniques, check out our other blogs on Sliding Window, Token Bucket, and Concurrency limiters.
